AB102104
Grooved Terrain In Channel Between Hydaspis Chaos And Ares Vallis
Latitude:  6.14°     Longitude:  23.92° W     Resolution:  2.76 m

Width 1024 pixels 2.82 km
Height 3840 pixels 21.56 km
Altitude 366.93 km
Slant Range 367.01 km
Crosstrack Summing 2
Downtrack Summing 2
Corner Coordinates (lat, lon)
6.24°   23.79° 6.24°   23.75°
5.88°   23.84° 5.88°   23.79°
Emission Angle 1.22°
Incidence Angle 77.61°
Phase Angle 77.88°

Midsized JPEG Full-Scale JPEG PDF File TIFF File Process Image Process Raw Image
512x3955 | 393 K 1024x7910 | 1365 K 3934 K 6654 K Small | Medium Small  |  Medium

Note: To the extent possible, this MOC image has been placed in the Viking MDIM context image by registration with geographic features.


Location of MOC image is approximate.
